Product Catalog

DOWNLOAD SPEC

Getting Started

API Access will require oAuth authentication, please refer to the details on portal.



Get Products

Method GET
BaseURL https://api.se.com/v1/reference-data/product/product-catalog
ResourcePath /products



QueryParams:

Param Data-type Mandatory Example Description
supplierid string Y 99887766 Product supplier identifier, configured in the Schneider Electric product master system.
supplierid-type string Y

specific

(DUNS) ID number if available, else (Specific)

Available values: specific, duns
Default value: specific
customerid string Y 1122334455 Your Customer identifier (Duns if available) or the one configured in the Schneider Electric product master system (delivered by your Sales contact)
customerid-type string Y specific (DUNS) ID number if available, else (Specific)

Available values: specific, duns
Default value: specific
date-of-reference string N 2021-12-01 Starting date for any changes made to product data, which is used to query for delta changes.
change-type string N all Type of changes of interest since the date-of-reference.

Available values: new, update, delete, all
Default value: all
product-reference string N QA_4659_DES_22 One or multiple product references, entered as individual query parameters.
product-identifier string N

commercialReference

Product reference type, commercial reference or gtin.


Available values: commercialReference, gtin
Default value: commercialReference

etim-version string N

ETIM-7.0

ETIM version, where ETIM is a standard for classifying product data.

Available values: ETIM-7.0, ETIM-8.0
Default value: ETIM-7.0

english-descriptions boolean N

true

Whether or not English descriptions are included in addition of the local language

Default value: false

mime-filtering string N MD36

In this filter, provide multiple mime descriptor code such as MD01,MD04,MD99,etc. For the requested mime-filter all the doc-types associated with the mime descriptor code will be returned along with the doc-type which are allowed for the respective data-filters. - MD01 for Image of product - MD04 for Product Page Link - MD05 for REACh Declaration - MD14 for User guide - MD14 for System user guide - MD14 for Quick start guide - MD21 for Instruction sheet - MD22 for Product Data Sheet - MD36 for RoHs Declaration / RoHS China Declaration - MD99 for CAD / 3D Model / How to video / Promotional video / 360 set of image / Product environmental / End of life manual / Brochure / Catalog

Available values: MD01, MD04, MD05, MD14, MD21, MD22, MD36, MD99

data-filtering string N up-selling

Product data filter. By default all data is returned but this allows a specified set of data to be requested. These are the supported values that can be used to return filtered data : all, etim, marketing, logistic-sales, followup, digital-asset-media, relationship, accessories, mandatory, select, spare-part, similar, cross-selling, up-selling

Definition :
all: all data related to the product (this is the default option)
- etim: only ETIM classification, features and valuation data
- marketing: only marketing data such as descriptions, keywords, assets
- logistic-sales: packing units data, ordering and pricing information - followup: only product substitution data
- digital-asset-media: only the mimes part for media assets ( How To Video, Image of product, Image of product in real life situation, Promotional Video)
- relationship: all the product relationship (except obsolete substitution)

If you want to return specific Product relationship, these values can be used instead of relationship :
- accessories: optional product accessories
- mandatory: mandatory additional product
- select: selectable additional product that cannot be ordered alone
- spare-part: replacement parts
- similar: Schneider Electric alternative product
- cross-selling: related or complementary items
- up-selling: comparable higher-end product

Available values: all, etim, marketing, logistic-sales, followup, digital-asset-media, relationship, accessories, mandatory, select, spare-part, similar, cross-selling, up-selling
Default value: all
